OEM Medical Grade Silicone Rubber Products Injection Molding

Product Details

Place of Origin: CHINA

Brand Name: OEM

Certification: SGS,ROHS,ISO

Model Number: OEM

Payment & Shipping Terms

Minimum Order Quantity: Mold: 1 set, Products: 2,000pcs

Price: USD, Negotiation

Packaging Details: as your requirement

Delivery Time: 10~30 days

Payment Terms: T/T, L/C, Western Union,Paypal

Supply Ability: 20sets, 500,000pcs/month

Get Best Price
Highlight:

OEM Silicone Rubber Injection Molding

,

Medical Grade Silicone Rubber Injection Molding

,

OEM Silicone Rubber For Mold Making

Mold Material:
High Quality Die Steel
Products Material:
Liquid Silicone
Ejection Type:
Stripper Plate, Ejection Pin, Etc.
Mould Life:
1,000,000~3,000,000 Molds
Product:
Medical LSR Products
Max. Mould Size:
Biggest Mould Made Is 600mm X600mm X 600 Mm,etc.
Cavity:
According To Your Needs
Surface Treatment:
High Polishing, Mirror Surface, Etc.
Advantage:
High Wear
Mold Material:
High Quality Die Steel
Products Material:
Liquid Silicone
Ejection Type:
Stripper Plate, Ejection Pin, Etc.
Mould Life:
1,000,000~3,000,000 Molds
Product:
Medical LSR Products
Max. Mould Size:
Biggest Mould Made Is 600mm X600mm X 600 Mm,etc.
Cavity:
According To Your Needs
Surface Treatment:
High Polishing, Mirror Surface, Etc.
Advantage:
High Wear
OEM Medical Grade Silicone Rubber Products Injection Molding
Medical Grade Silicone Injection Molding,Customized high-quality LSR liquid silicone rubber injection mold


Product Introduction



Silicone Injection Molding

Silicone injection molding is widely used in the production of medical silicone products and food-grade silicone products. Its advantages are high production efficiency and good quality, which can save the process of manual repair of burrs. Meanwhile, it can be produced in a clean workshop to avoid workers working in high temperature.



Product Specifications



Products material Liquid silicone
Ejection Type Stripper Plate, Ejection Pin, etc.
Cavity According to your needs
Surface treatment High polishing, Mirror surface, etc.



Product Pictures



Liquid silicone injection molding can produce parts with complex structure. Liquid silica gel injection molding is suitable for mass production and complex shape products and other molding processing fields.The injection molding process of liquid silica gel can be roughly divided into six stages, that is, mold closing, injection, pressure holding, cooling, mold opening, product taking out.



In this process, the quality of liquid silica gel injection products is generally related to temperature, pressure, time.The improvement of temperature control can be carried out from three stages: barrel temperature, nozzle temperature and mold temperature.The nozzle temperature is usually slightly lower than the high temperature of the barrel, the principle is to avoid liquid silica gel in the nozzle vulcanization forming blockage.





OEM Medical Grade Silicone Rubber Products Injection Molding 0



Mold temperature can be divided into three parts: heating, heat preservation, cooling.Mold temperature determines the condition of liquid silicone vulcanization, the size and structure of injection parts, performance requirements and other process conditions.

  1. Control of liquid silicone injection molding pressure: The pressure control in injection molding is divided into plastic pressure and injection pressure, and directly affects the quality of injection parts.

  2. Plasticizing pressure: silicone injection molding machine using screw injection machine, the top of the screw melt in the screw rotation back by the pressure is called plasticizing pressure, also known as back pressure.The pressure can be adjusted by means of a relief valve in the hydraulic system.The increase of plasticizing pressure is proportional to the strengthening of shear action, which can increase the temperature of hot vulcanized silicone rubber material, and vice versa.

  3. Injection pressure: the injection pressure of liquid silicone injection machine is calculated based on the pressure applied to liquid silicone rubber at the top of plunger or screw.The role of injection pressure in injection molding is to overcome the flow resistance of silicone rubber material from the barrel to the cavity, to give the rate of silicone mold filling and to compress the silicone rubber.



OEM Medical Grade Silicone Rubber Products Injection Molding 1

OEM Medical Grade Silicone Rubber Products Injection Molding 2

OEM Medical Grade Silicone Rubber Products Injection Molding 3



We are a professional manufacturer of silicone rubber products, specializing in the customized production of all kinds of food grade and medical grade silicone rubber products, with more than 15 years of experience in silicone rubber processing, with precision mold design and manufacturing technology, welcome to contact us at any time, query related products and quotations.
